Power Integrations, the leader in high-voltage integrated circuits for energy-efficient power conversion, announced a high-current member of its LinkSwitch-TN2Q automotive switcher IC family which provides up to 850mA of output current without the need for metal heatsinking.

The highly integrated ICs support a wide input voltage of 30 to 550 VDC, enabling the devices to start up and operate below the required Safety Extra Low Voltage(SELV) threshold in functional safety EV applications.

Edward Ong, senior product marketing manager at Power Integrations, said: “As electronics in electric vehicles grow more sophisticated, automotive customers need higher supply currents to drive them.” said Edward Ong, senior product marketing manager at Power Integrations.

“The 850-mA rating for this new IC represents an increase of 230 percent in available output current compared with other members of the LinkSwitch-TN2Q family. LinkSwitch-TN2Q ICs reduce part-count by including control, driver, protection circuitry and a 750 V power MOSFET in an SMD package.”

LinkSwitch-TN2Q ICs are AEC-Q100 qualified and support buck, buck-boost and non-isolated flyback converter topologies.

Each device incorporates a 750V power MOSFET, oscillator, on/off control, a high-voltage switched current source for self-biasing, frequency jittering, fast(cycle-by-cycle) current sensing and current limit, hysteretic thermal shutdown, and output over-voltage protection circuitry in a monolithic IC.

LinkSwitch-TN2Q ICs consume very little current in standby, resulting in power supply designs that easily meet less than 50mW no-load at 400VDC input.

Comprehensive protection features enable safe and reliable power supplies, including protection against input and output overvoltage, device over-temperature, lost regulation, and power supply output overload or short-circuit faults.
